Lesion Generator -2 channel


Adapt symptoms: suit for trigeminal neuralgia and primary Intervertebral Disc pain that is ineffective after regular conservative treatment.
Relative Products:
Reusable RF electrode probe, Single Unified electrode RF cannula, Single use RF cannula

We're here to help:
Easy ways to get the answers you need.

Product parameters

Radiofrequency Ablation for Pain Management

  1. RF frequency:440KHZ±40KHZ Sine wave

Working voltage:220±10%  50Hz±1Hz.

  1. Therapy output power: ≤20W (Adjustable)
  2. Standard RF damage mode

Have Auto control and manual control mode,

damage temperature and time are adjustable.

Temperature setting scope: 50°C-95°C.

Temperature measure scope: 25°C-95°C

  1. Time setting scope:10s-5min.
  2. Pulse RF temperature: 42°C±2°C.

Pulse RF width control mode: 10-50 ms

Pulse RF frequency mode: 1-8 Hz.

Could change with continuous RF freely

  1. Impedance measure scope: 50Ω-1000Ω.
  2. Stimulation Mode

Stimulation pulse width: 1-3ms

Stimulation pulse amplitude: 0.1-5.0V continuous adjustable

Stimulation pulse frequency: 1Hz-90Hz

  1. High temperature protection function

Therapy temperature scope more than 5°C, lesion generator will stop working.

  1. Machine screen size: 7″, screen resolution: 800×480.
